Multi Lane Ketchup Paste Filling And Packing Machine

Introduction



The Multi Lane Ketchup Paste Filling and Packing Machine is a marvel of engineering and innovation. It is a state-of-the-art machine that has been designed to provide efficient and reliable filling and packaging services for ketchup and other paste-like products.

One of the most striking features of the Multi Lane Ketchup Paste Filling and Packing Machine is its ability to handle multiple lanes of packaging simultaneously. This allows for greater productivity and throughput, as well as minimizing downtime and inefficiencies.

The machine is also equipped with advanced sensors and controls that monitor and regulate the filling process, ensuring that each package is filled to the correct level and that product waste is minimized. This not only saves time and money but also ensures that the end product meets the highest standards of quality and consistency.

it is can automatic filling forming sealing date printing and finish product conveyor function.





Feature

The Multi Lane Ketchup Paste Filling and Packing Machine is an innovative and efficient solution for businesses looking to improve their packaging process. This machine offers a number of features that make it an ideal choice for companies of all sizes.

One of the key features of the Multi Lane Ketchup Paste Filling and Packing Machine is its ability to fill multiple lanes simultaneously. This means that companies can fill more packages in less time, which can help to increase productivity and reduce costs. Additionally, the machine is highly accurate, ensuring that each package is filled to the correct level without any spills or mess.

Another important feature of the Multi Lane Ketchup Paste Filling and Packing Machine is its versatility. This machine can be used to fill and pack a wide range of products, including ketchup, paste, sauces, and other viscous liquids. Companies can customize the machine to suit their specific needs.   www.rulangmachine.com











Application
Suitable to pack liquid or paste or sauce materials, such as shampoo, ketchup, jelly, sauce,juice. etc

Fully automatic liquid filling machine 4 lane 6 lane 8 lane and 10 lane packing machine
Multi lane small sachet liquid stick bag honey sauce ketchup packing machine
Stick water ice pop ice lolly oil juice filling sealing machines



Sample bag



Specification

Model	RL-480YT	RL-720YT	RL-960YT
Lanes number	4~6 lanes	4~10 lanes	4~12 lanes
Capacity	Max.40 bags/min/lane
Film material	Laminated film, laminated paper film, Pure Aluminum film
Bag size	L:45--120mm
	W:35-60mm	W:35-90mm	W:35-120mm
Film width	Max.480mm	Max.720mm	Max.960mm
Film thickness	0.05--0.1mm
Sealing type	4 sides sealing
Power supply	1N+PE/50HZ/AC220V
Power	2.8KW	4.1KW	5.5KW
Air consumption	0.8 MPA 0.8m3/min
Dimension(mm)	950*1470*1750	1153*1654*1750	1415*1686*2130
Weight	300kg	400kg	500kg
Function	Be able to weight, fill, make the bag, print manufacture date and expiry date and batch number, seal, cut off automatically

FAQ

1) Q: How do I choose the right type of machine?
A: Please provide the following info for us to make a solution to meet your unique product packaging requirements with the lowest costs.
* What is the product (picture or short video clip better);
* Packaging bag size (length/width), volume in each bag;
* Bag type:
- Premade bag (doy bag, block bottom bag, gusseted bag, 4 side seal bag, etc); with or without euro hole, easy tear open; plastic bag or paper bag;
- Packaging film form-fill-seal bag (3 side seal bag, 4 side seal bag, pillow bag, stick pack, etc); with or without euro hole, easy tear open.
* Outputs requirements (speed)
* We will send you machine working video for your requirement.















Packing and shipping



Welcome to send inquiry about our multi lane paste packing machine!
